¶ General
General settings for e-mail, devices and credentials.
¶ Card Formats
Various supported card formats can be enabled/disabled for CredoID system. Disabled card format will be not accepted by CredoID.
Only single same bit lenght format can be enable at a time.
Maximum of 8 card formats are supported by the controllers.
- Enable card format - Select format from the list to enable it.
- Click to remove one of enabled formats.
- Click to add a facility code (only for supported formats).
Press Save to save enabled formats. Synchronization of devices will be required.
HID Aero support up to 8 facility codes per controller.
Mercury support up to 16 facility codes per controller.
¶ Excluded events
Events can be filtered and excluded either completely or just from archive only.
Excluded events won't be saved to database therefore some disk space will be saved.
Past events will not be affected by this setting.
¶ Notifications
These settings will be used each time, when creating new trigger action send email.
- Outgoing SMTP server - Your e-mail providers SMTP server address.
- Port - Port for outgoing mail server.
- From email - E-mail address which will be displayed for recipient.
- Username - Username for SMTP server.
- Password - Password for SMTP server.
- Enable SSL - Enable secure socket layer (encryption).
¶ User Import & Reset
- Enable user import - Global settings for selecting primary key for user import, it's either "First and last name" or "Employee number". All users are required to have unique primary key in the import source.
- Reset card use limit - set how often card use limit is reset using cron expression.
¶ License Owner
Enter license owners name and it will be shown in main menu instead of "License".
¶ Mobile ID
Mobile ID providers can be added in this section. Also, you can check the current connection status, edit provider or remove it.
Please follow further instructions on how to setup and issue Mobile ID
- Add new mobile ID provider - Select Mobile ID provider you want to set up.
- Check status of Mobile ID provider.
- Edit details of Mobile ID provider.
- Remove mobile ID provider.
¶ Password policy
Starting from version 4.16.140 release, we are introducing a password policy settings along with password security improvements.
- Operator lockout - Set amount of failed attempts after which the user will be locked out for set duration of time.
- Password expiration - Set default value of time duration (days) that will be set when creating a new operator with "Password expiration" check mark.
- Special Character - Requires a non-alphanumeric character in the password.
- Lowercase - Requires a lowercase character in the password.
- Uppercase - Requires an uppercase character in the password.
- Digits - Requires a number between 0-9 in the password.
- Minimum unique characters - Requires the number of distinct characters in the password.
- Minimum lenght - The minimum length of the password.
¶ Backup & Restore
Create and restore backup and set automatic backups. Backup will consist of current database snapshot, configuration files and media such as profile images, map backgrounds etc.
Create button will instantly create a backup.
Restore button restores data from a selected backup.
You can also enable automatic backups and select how often they will be created.
Default backup storage directory is C:\ProgramData\Midpoint-Security\Backup.
It can be changed by editing backup path field.
Backup should be restored only for the same version. Restoring previous backup on top of newer CredoID might break functionality.
Backups can be downloaded by clicking
in the actions column.
To delete backup click on in the actions column.
¶ Clean-up
Set automatic clean-up for events, users and backups.
CredoID will run automatic clean-up check each hour. Clean now allows to start check right away.
Any of the modified settings be saved by clicking Save before clicking Clean now.
- Delete events older than ___ days - Automatically delete events that are older than set amount of days.
- Delete archived events older than ___ days - Automatically delete archived events that are older than set amount of days.
- Delete event ___ count - Only keeps set amount of events in the database.
- Delete backup files older than ___ days - Automatically delete backup files that are older than set amount of days.
- Delete expired users older than ___ days - Automatically delets expired users that are older than set amount of days. Expired user is defined by "Expiration date" in "Users" menu.
- Delete inactive users older than ___ days - Automatically delete users if they haven't received any of "Access granted" events in set ammount of days.
- Scheduled reports retention ___ days - Automatically delete scheduled reports older than set amount of days.
- Scheduled reports rotation ___ count - Only keep set amount of scheduled reports in the system.
¶ Devices
Global device related settings such as PIN code length and OSDP reader LED & Beeper templates.
¶ PIN Readers
Set PIN code length accepted by CredoID and readers with keypad (if supported).
¶ LED & Beeper
Using OSDP readers in the system allows you to configure LED & Beeper behaviour. You can have up to 3 templates that can be configured and applied to each door.
"Default template" is configured to match controller manufacturer default configuration and is used as default when creating new door.
This feature is supported only with HID Aero and Mercury controllers.
- Reader Mode - Reader modes, i.e. what happens with LED & Beeper when user gets "Access Granted".
- On/Off color - Set readers color during certain modes on/off state.
- On/Off Time - Set how many ticks(0.1 s/tick) each state will last.
- Repeat count - Set how many times on/off cycle will be repeated.
- Beep count - Set how many times reader will beep on credential read.
When using "Card & PIN" reader mode - reader goes into "PIN only" mode after swiping card first or into "Card only" mode after entering PIN first. LED changes accordingly.
Available colors:
¶ Logs
Change logging level and download logs.
Sorting from highest to lowest, logging level can be set to:
- Trace
- Debug
- Information - Default
- Warning
- Error
- Critical
- None
Logs can be downloaded by clicking in the actions column.
Stored logs can be found at C:\ProgramData\Midpoint-Security\CredoID Service\Logs
This information is necessary to provide when requesting CredoID support. Please enable "Debug" if you have a repeating issue and submit the logs to our support desk.
